Santa Cruz Bullit CC XT MX

Santa Cruz Bullit CC XT MX
$6,799.00
Color: Gloss Lavender and Yellow
Size: Large
Please select options Unavailable

Details

What goes up, loves coming down

The Bullit is an electric mountain bike designed for tackling the steepest and deepest of trails in both directions. Imagine the kinds of rooty, rocky, horror fests usually reserved for our biggest-hitting bikes like the Nomad and Megatower. Then imagine what lies beyond that.

Where the Heckler's priority is agility and playful handling, the Bullit takes more of a no-limits approach. 170mm travel, a 38mm fork, and DoubleDown tires reflect the smashability of this platform. This is a bike for riders who seek V10-level terrain that's out of range of any chairlift or shuttle road.

It was actually the Santa Cruz Syndicate team's success on their mixed-wheel DH race bikes that made us consider the same format for the Bullit. We learned from them that mixed wheels provide the confidence at speed of a 29er with the more spritely handling characteristics and maneuverability of a 27.5-inch rear wheel. And, for an e-bike, it also means we can dictate exactly how long (or short) we want to make the chainstays to balance climbing traction and handling. The added butt clearance on super steep stuff is just another bonus.

The biggest trails take a bigger commitment to reach them. Thankfully Shimano's commitment to the STEPS EP8 motor means we have a lighter, more powerful (85Nm), more compact, and more efficient way of reaching them. The EP8 is also tuned to give more power in Trail mode without affecting range. So, paired with Shimano's biggest 630wh battery, it ensures the Bullit is fully equipped for long, tough climbs to the longest, toughest descents.

bike frame with labeled dimensions
Bike Sizes:
MLXLXXL
A. Reach 450mm 475mm 495mm 515mm
B. Stack 621mm 630mm 648mm 670.4mm
C. Standover 748mm 747mm 745mm 745mm
D. Effective Top Tube 591.3mm 619.2mm 644.9mm 672.1mm
E. Head Tube Angle 64° 64° 64° 64°
F. Head Tube Length 100mm 110mm 130mm 155mm
G. Seat Tube Angle 77.2° 77.1° 77° 76.8°
H. Seat Tube Length 405mm 430mm 460mm 500mm
I. Bottom Bracket Height 348mm 348mm 348mm 348mm
J. Bottom Bracket Drop 25.5/6.5mm 25.5/6.5mm 25.5/6.5mm 25.5/6.5mm
M. Wheelbase 1238.5mm 1267.9mm 1296.7mm 1327.7mm
N. Front to Center 789.4mm 818.8mm 847.5mm 878.5mm
O. Chainstay Length 449mm 449mm 449mm 449mm

Specs

Frame XT AIR
Fork FOX 38 Float Performance Elite, 170mm
Rear Shock RockShox Super Deluxe Select+
Rims RaceFace ARC HD 30 (29” F, 27.5” R)
Hubs Front: DT Swiss 350, 15x110, Centerlock, 32h
Rear: DT 350, 12x148, MicroSpline, 32h
Spokes Sapim Race
Axles Front: 15x110mm
Rear: 12x148mm
Tires Front: Maxxis Assegai 29"x2.5", 3C, MaxxGRIP, Double Down, TR
Rear: Maxxis Minion DHR II 27.5"x2.4, 3C, DoubleDown, EXO, TR
Crankset Shimano XT M8150 Crank Arms, 165mm
Shifters Shimano XT M8100, 12spd
Rear Derailleur Shimano XT M8100, 12spd
Cassette/Freewheel Shimano XT M8100, 12spd, 10-51t
Chain Shimano XT, 12spd
Brakes Shimano XT 8120
Rotors Shimano XT, Ice Tech, Centerlock, 203mm
Handlebars Santa Cruz e35 Carbon Bar, 800mm, 35mm Rise
Tape/Grips Santa Cruz House Grips or Burgtec Bartender Pro Grip Minnaar
Stem Burgtec Enduro MK3, 42.5mm
Headset Cane Creek 40 IS Integrated
Seatpost Fox Transfer Performance Elite
Pedals Sold separately
Accessories & Extras E13 E-Spec+ AL
Motor Shimano Drive Unit DU-EP800
Battery Shimano 630Wh Integrated
Controller/Display Shimano Display Unit SC-EM800

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Gloss Lavender and Yellow / Large 192219234564 58-22234-149-4-719-787201-01 210000000552
